| Title | Graphite (100x) |
|---|---|
| Date | August 6, 2025 |
| Pseudo-color | Rainbow Color |
| Measurement System |
OptoNume SN507-P |
| Interference Objective Lens |
Nikon CF IC EPI Plan DI 100x |
| Field of View | 111 μm x 111 μm |
| Averaging | 10 |
| Display Range |
-3 to 5 μm |
| Sa | 1.643 μm |
